| Model | PanoGrad |
| Column Height | 230cm |
| Vertical Movement | Motor Driven |
| Generator | LF 50Hz/40Hz |
| kVp Range | 50-85kVp |
| Tube Current | 20mA |
| X-Ray Tube | Stationnary Mode |
| Exposure Time | OPG- 17 Sec, CEPH - 0.2-3 Sec & TMJ - 4x4 Sec |
| Operating Console | Feather Touch digital Display |
| Film Size | OPG & TMJ - 6"x12" / 10"x12", CEPH - 8"x10" |
| Cassette Size | OPG & TMJ - Flat 6"x12" / 10"x12", CEPH Flat - 8"x10" (CR Compatible) |
| Power Requirement | 230V, 1 Phase AC with line regulation of +/- 5% |
